APPLICATIONS
- For Mock Safety Stitch - suitable for seaming sides and joining front and side panels on ladies' swim suits, childrens' play pants; closing sides on ladies' panties; setting sleeves on ladies' uniform dresses and knitted sport shirts; sewing cuffs to sleeves and attaching pocket pieces to front and back on ladies' robes; setting body lining on men's raincoats, etc. Equipped to handle medium to heavy weight materials and designed for sewing stretchable materials or fabrics which need elasticity in stitching.
FEATURES
- Speed, Max. up to 7500 s.p.m. (depending on thread, material and application)
- Fully automatic lubrication with visual flow controls
- Lubricating oil continuously filtered by replaceable filter
- External cooling of oil supply
- Silicone based needle cooling and lubricating system
- Differential feed with micrometric adjustment for shirring and stretching. Ratio up to 4 to 1.
- Push-button stitch regulator
- Intermittent action possible
- Standard type B-27 needles
- Reduced noise and vibration when operating at high speeds
SPECIFICATIONS
| Number of Needles | 2 (Double) |
| Feeding Mechanism | Differential |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 7500 |
| Max Stitch Length | 3.8mm |
| Presser Foot Lift | 5.5mm |
| Overedging Stitch Width | 3-5mm |
| Differential Ratio | 1 : 0.7mm ~ 1 : 2 |
| Two Needle Needle Distances | 2 mm |
| Number of Threads | 4 |
